目录说明

Key Features

• SLC (Single-Level-Cell) NAND flash and
MLC (Multi-Level Cell / 2-bit per Cell)
NAND Flash
• Advanced Wear Leveling algorithm
• Bad Block Management
• Read Disturb Protector - AutoRefresh
to ensure data integrity during read
operation
• IP67 waterproof/Dustproof test
(IEC 60529)
• Highly reliable and pass environmental
test (Bend/Torque/Salt Spray/Solar
radiation)
• ESD resistance
• Life Monitor (Note : The compatibility and
support of Life Monitor may vary on different
platform/operation system)

Applications

• Industrial PC
• Medical devices
• Automation
• Automotive IVI systems
• Test and Measurement
• Surveillance systems
• Drive recorders
• Navigations
• Network cameras
• Mobile/Handheld computers






详细介绍




ATP Industrial Grade SD/SDHC/SDXC cards are designed for application in demanding industries, such as automotive, healthcare, and aviation,where critical data requires the highest level of reliability, durability, and data integrity. They are also suitable for removable application and small footprint mechanism devices.ATP SD cards with read disturb protector-AutoRefresh technology and Autoscan features are best suited for read intensive applications. For instance in the automotive industry, ATP SD cards have been recognized by worldwide major tier 1 Auto Infotainment Suppliers and tier 2 telematics electronic vehicle system developers/service providers for their map system, IVI (in-vehicle-infotainment), and OS boot-up. On the other hand, ATP SD cards with SLC mode and Power cycling solution are ideal for write intensive applications. Such applications include data logging and storage of hospital medical devices and surveillance systems.Moreover, with ATP's SIP (System-In-Packaging) manufacturing process, the operating/ storage temperature of ATP Industrial Grade SD cards is -40 to 85 degrees Celsius. All ATP Industrial Grade products go through multi data pattern burn in test. This is to screen for early fallout occasionally seen in any semiconductor technology.
